MODEL 23 REAR CABLE CONTROL UNITS

The Cat 23 Cable Control Unit, a rear cable contrl unit, uses the same discs as the D4 steering clutches. The 23 CCU uses 7 bimetallic and 6 steel discs per side.  (NOTE.........THE 23 CABLE CONTROL UNITS USED SMALLER DISCS than the Cat 25 cable control units but they look identical from the outside.   Be sure which you have before ordering!)

ORDERING INFO:
GRIMY_Man_SM.jpg (55040 bytes)  We can usually ship on the same day any items we have in stock that do not have to be pulled from a machine.
We are set up to offer the payment choices of either Visa, Master Card, or the PayPal option (to the account of webmaster@tractorparts.com)
All items below are in stock and if you would like to get any of them on the way just let us know!  If you are in the US you may call  1-800-531-9021 or if you are outside the US, 1 208 342 8911.  You may also email steeringclutch@gmail.com    for orders/questions.

Our hours are Monday through Friday from 10 am Eastern Time to 6 pm Eastern Time (8 am Mtn Time to 4 pm Mtn Time).  We are located 20 miles east of Boise, Idaho.

If you are replacing all discs on one side of the CCU, 7 friction and 6 steel the cost is $207.00

D4 CLUTCH DISCS.JPG (87624 bytes)

Late D4 7U 3F5504 (qty 7 per side) Bimetallic fricton discs @ 21.00 ea


D4 2B8955 (EARLIER P/N 3F9073) (qty 6 per side) Steel Discs $12.00 EA.

CAT D4 STEERING CLUTCH PACK

BRAKE BANDS

CAT_24_CABLE_UNIT_5F833_5F0833_4F2918_BRAKE_BAND.jpg (239955 bytes)  Brake bands with new heavy duty linings.  If you have to replace the whole band, a complete band, good used band with new linings, would be 248.00   Part numbers for the band can be: 5F833 , 5F0833, or 4F2918

BRAKE LINING KIT



DRY TYPE BRAKES, BRAKE LINING KIT, INCLUDES RIVETS, LINING FOR ONE BAND ...........$84.00
HEAVY DUTY WOVEN LINING WOVEN WITH BRASS STRANDS, DESIGNED FOR REPEATED USE IN SEVERE CONDITIONS, ABLE TO WITHSTAND HIGH TEMPERATURE USE (400 DEGREE)WITH MINIMAL LOSS OF COEFFICIENT OF FRICTION.

Click HERE to view all of our new steering clutch & friction discs.


Email steeringclutch@gmail.com   tractor_parts_email for orders or questions.

visasmalllogo MClogoshrunk
CONTACT OUR OFFICE at 1-208-342-8911

General Gear and Machine, 733 Desert Wind Rd., Boise, Idaho, 83716  US
*All prices are in USD & do not include shipping
All prices are for new aftermarket unless stated otherwise
All OEM part numbers are for references only
